Micro Brewery System Craft Equipment 500l Brewing Beer 500 Liter Brewery beer machine

  • 1 - 2 Sets
    $32,000.00
  • >=3 Sets
    $31,000.00
Model Number:
MT-5BBL MT-500L
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 Negotiable
Samples:
$30,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Warranty:
3 years
After-sales Service Provided:
Online support
Place of Origin:
Anhui, China
Brand Name:
METO
Voltage:
220V/380V/Adjustable
Weight:
Depends on equipment
Processing Types:
beer
Certification:
CE ISO TUV
Dimension(L*W*H):
Depends on equipment
Power(W):
15-70Kw Depends
Applicable Industries:
Hotels, Food & Beverage Factory, Restaurant, Home Use, Food Shop, Food & Beverage Shops
After Warranty Service:
Video technical support, Online support
Local Service Location:
Canada, United Kingdom, United States, Italy, France, Germany, Philippines, India, Mexico, Russia, Thailand, Japan, Argentina, South Korea, Chile, Colombia, Romania, South Africa, Ukraine
Showroom Location:
Canada, United Kingdom, United States, Italy, France, Germany, Philippines, Peru, Indonesia, India, Mexico, Russia, Spain, Thailand, Argentina, South Korea, Chile, Colombia, Romania, South Africa, Ukraine, Japan, Malaysia, Australia
Material:
Full stainless steel SUS304
Welding:
Arc Argon Protection
Technology:
Offer Auto Cad and 3D design drawing
Material Thickness:
Inner wallet 3MM outter wallet 2mm
Electric elements:
Up to CE Standard
Brewhouse heating:
Steam jacket,electric tube,Direct Fire
Fermenter:
Double wallet with dimple cooling jacket
Cooling Unit:
Chiller with Glycol Tank
Control Unit:
Temp. Controller ,HMI , PLC or touching screen
Polish Finish:
0.4-0.6Um
Product Certification certification
CE Certified.
Valid from 2016-08-16 until 2021-08-15
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export standard Plywood case for LCL
Plastic film wrapped and steel frame fixing for FCL
Port
QingDao/Tianjin
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 To be negotiated







Product Description

Micro Brewery System Craft Equipment 500l Brewing Beer 500 Liter Brewery beer machine





2 Vessel Brewhouse 3 Vessel Brewhouse

Mash/Lauter tun+Brew kettle/whirlpool tank

1.Lauter&storage tank+brew kettle/whirlpool tank

2.Lauter&whirlpool tank ,+brew kettle

3.Lauter&HLT +brewkettle/whirlpool tank

Combined 3 Vessel Brewhousez 4 Vessel Brewhouse
1.Mash/lauter tun+ brew kettle +whirlpool tank

2.Mash tun+ lauter tank + brewkettle/whirlpool tank

 Mash tank +lauter tun + brew kettle+whirlpool tank









Fermentation Tank Main Composition
Butterfly head,Top /Side Pressure manway , Dimple plate cooling jackets , L pipe (1piece/2 pieces ) ,Safety Valve , Water-seal pressure valve, Sterile sampling valve , Sanitary butterfly valve ,360°CIP Ball , Inlet and outlet of cooling media , PT100 , Wort outlet , drain outlet , Bottom removable device,Stainless steel Leg, Adjustable pad







Brewing SystemComponentsCapacity Specification
Milling SystemMiller 200 KG/HDouble Roller,Noise<60db
Heating SystemBoiler50 KG/HElectric,Gas,Oil,Coal Type/CE certification
Brewhouse System Mash/Lauter tun500L

Mashing Process:Decoction.Infusion.Multi-step infusion
Heating source:Steam,Electric,Gas
SUS304/Red copper

Remarks: For smaller pub brewery equipment, we offer Combination 2-vessel brewhouse:

Mash/Kettle + Lauter tun/Whirlpool Combined.

Brew Kettle/
Whirlpool Tank
500L
Hot Water Tank 1000L
Heat exchanger5 SQMStainless steel plate
Fermentation SystemFermentation Tank 500L / 1000LTop manway/Side manway
Drying hop port to brew IPA
Dimple Plate Cooling jacket
Carbonation port to fill CO2
Yeast Adding Tank5L / 10LSUS304 Stainless Steel
Cooling System Glycol Water tank 1500LEquiped with PU level indicator
Chiller 5HPUL/CE certified electric elements,Copeland compressor
Pump3T
Cleaning System Disinfection Tank100LSUS304 full welded
Alkali Tank100L
Pump3T
Control System Control Cabinet PID / PLCManual/Semi-automatic/Automatic
Optional Auger System
Grain Case
Grist Hydrator
Piping flow panel for Brewhouse



PS: All the specifications can be customized according to your requests.



Project Show





Packaging & Shipping

Our Services





Company Information



FAQ



1.Q: Are you a manufacturer?
A: Yes, we have been in providing the professional products in this field for 10 years.



2.Q:What exactly does the 36 month warranty cover?
A:36 month warranty cover all the main tank.one years for the accessories and spare parts.



3.Q: Can your factory produce equipment according to our drawing or samples?
A: Yes, we can do.



4.Q:Is the 15 day set-up by your engineers mandatory, or can we opt to pass on that service?
A:Yes ,you can,we will offer the manual or video to let you know how to connect the equipment.



5.Q: How to calculate the daily output? How many fermenters do I need?
A: Usually theequipment models such as 300L and 500L are only 300L, 500L wort for mashing capacity. Beer production is according to your fermentation process requirements and the number of fermenters configured.



6.Q: How you pack the products?
A: Normally as the export standard packaging or as you required.

7.Q: What is your available port of shipment?
A: Qingdao port,shanghai etc.
